Ripening Gas (Ethylene / C2H4) Transmitter

The Ripening Gas transmitter by PDSA is a well-established sensor in the Australian cold room industry. The transmitter utilises a Photoionization detection process and allows for continuous measurement of ethylene and other volatile organic compounds at 0-100 or 0-1000ppm ranges.

Not available online.

Product Documents


The RG sensor can accurately detect ethylene for low and high level ripening, de-greening and other monitoring applications. Designed for long term deployment the PDS-EC-TX-RG3 is sensitive and stable, suitable for clean cold rooms where ethylene precision is required to optimise quality and gas usage, saving money and delivering uniform colour, fresher, tastier produce.

Ranges Available:

0-10ppm / 0-200ppm / 0-1500ppm


Model No: PDS-EC-TX-RG3

This is the only fixed measurement solution operators should consider for ethylene monitoring.

Fixed ethylene detection in cold rooms gives operators and managers more confidence and control over room conditions. This leads to savings by optimising ethylene gas use and other catalytic generators. By monitoring the conditions and produce outcomes, operators can learn the best conditions for their product and reduce wastage and improve quality by having confidence in the environment.

Traditionally operators have relied on portable sensors and observation of the produce to make estimations about ethylene levels in rooms. These practices are inferior to the reliable fixed measurement of ethylene with around the clock readings and confidence in results and rooms.


The Effects of ethylene during the ripening of climacteric fruits

Ethylene production is closely associated with fruit ripening in climacteric fruits and is the plant hormone that regulates and coordinates the ripening process; colour development, aroma production and texture. Typically, climacteric fruit will generate barely detectable amounts of ethylene until ripening when there is a burst of production.

Ethylene as a ripening trigger is used commercially with many fruits including bananas, avocados and early-season kiwifruit to ensure that fruit are ripe when required. If the fruit is to be stored for a long time, then ambient ethylene must be removed from the room (usually by scrubbing this gas from the cool room).

The following table shows some appropriate ethylene gas levels, ethylene exposure times and temperatures for ripening certain commodities. Relative humidity should always be high, generally in the range of 80-95% for all commodities.


Appropriate ethylene and temperature levels for ripening and storage

Sensors - Ripening Gas (Ethylene) chart 2.png



Sensor Type: Electrochemical

Sampling Method: Diffusion

IP Rating: IP65

Range: 0-10ppm / 0-200ppm / 0-1500ppm

Resolution: 0.1ppm / 1ppm / 5ppm

Power Supply: 11…30VDC

Output: 4-20mA (Default), 0-10V, RS485 / ModbusRTU

Response: <60 seconds

Warm up time: 1 minute

Accuracy: +/- 5%

Temperature: -20 degC to +50degC

Humidity: 0 – 95% RH

Available for purchase as a standalone sensor, or as part of our complete package with our FreshView® EC12 Environmental Controller or FreshView® SmartStation.


FreshView® Sensors
High quality, robust sensing technology

  • Local support

  • High-quality sensing technology

  • Robust design

  • Water and dust resistant


We offer a range of high-quality Australian-made sensors for use in conjunction with, or independent of, the FreshView® EC12 Environmental Controller. Sensors are available for the detection of ripening gas (ethylene), carbon dioxide, temperature, relative humidity, pulp temperature and oxygen. Each sensor provides an analogue output signal and is housed in an enclosure that provides suitable protection against water and dust ingress (IP651). Sensors can be interfaced with other monitoring and control systems, including those manufactured by third parties.
